PC410L High Speed Optocoupler Isolator
Electrical Components
Buy Online PC410L High Speed Optocoupler Isolator from IndianLogisticsInfo.Com in Association with Amazon India
Product Details :
- Brand : Generic
- Manufacturer : Generic
- Country of Origin : China
- Number of Memory Sticks : 1
- Item part number : ST-2009SD0728
Product Features :
- Supply voltage: 7V; High-level output voltage: 7V; Reverse voltage: 5V; Forward current: 20mA
- Low-level output current: 50mA; Isolation voltage : 3.75kV; Power dissipation: 40mW; Collector power dissipation: 85mW; Soldering temperature: 270?C; Operating temperature: -40~85?C; Storage temperature: -40~125?C
- 5 pin Mini-flat package; Double transfer mold package (Ideal for Flow Soldering); High noise immunity due to high instantaneous common-mode rejection voltage (CMH: MIN.10 kV/?s,; CML: MIN. 10 kV/?s); High-speed response (tPHL: TYP. 48 ns, tPLH: TYP. 50 ns); High isolation voltage between input and output (Viso(RMS): 3.75 kV
- Applications Include:- Programmable Controllers; Power Supplies; Inverter
- Packaged by:- Sharvi Technologies (OPC) Pvt. Ltd.; Address:- #09, CK Nagar, AECS layout, Hosa Road, Bangalore-560100
